AQUASTRONG Sand Filter Pump Installation Guide

Introduction

If you're looking for a powerful and easy-to-install sand filter pump to replace your old pool pump, the AQUASTRONG sand filter pump might be the perfect solution. This guide will walk you through the entire installation process step by step, from unboxing to final operation, helping you easily upgrade your pool filtration system.

Unboxing and Parts Inspection

When you receive your AQUASTRONG sand filter pump, you'll find it's thoughtfully packaged with all components individually wrapped and well-protected:

• Main pump unit (2500 gallons/hour flow rate, suitable for pools up to 9000 gallons)

• 6-way valve assembly

• Sand filter tank base and tank body

• Central pipe and lateral assembly

• Various connection hoses and adapters

• Power controller (with 2-24 hour timer function)

• Accessory kit (includes Teflon tape, hose clamps, etc.)

• User manual and warranty card

Pro Tip: Immediately scan the included QR code to register your product warranty and keep all documents safe.

Parts Identification and Preparation

Before beginning assembly, check all 23 components against the quick installation guide:

1. Pump base

2. Pool pump main body

3. Pump cover

4. Pump drain cap

5. Sand filter tank base

6. Sand filter tank body

7. Central pipe assembly

8. Laterals

9. Drain valve

10. Air bleeder cap

11. Sand shield

12. Tank O-ring

13. 6-way valve

14. Waste outlet cap

15. Tank clamp

16. Sand filter interconnecting hose

17. 1.5-inch filter hose conversion kit (5 pieces)

18. Teflon tape

19. 1.25-inch hose adapter (3 pieces)

20. Hose clamps (3 pieces)

21. Pressure gauge

22. Viewing window

23. Green grounding wire (only needed for in-ground pools)

Assembly Steps

1. Pump Assembly

• Place the O-ring inside the pump cover groove

• Align the arrow marks on the pump cover with those on the pump body

• Press firmly and twist until locked in place

• Extend the pump base to desired position

• Secure the pump to the base using a 13mm wrench (avoid over-tightening plastic parts)

2. Sand Filter Tank Assembly

• Align and secure the sand filter tank base with the pump base holes

• Place the sand filter tank into the base, ensuring the drain valve aligns with base openings

• Insert the central pipe with laterals assembly into the tank center

• Cover with the sand shield

3. Adding Filter Media

Instead of traditional sand, we recommend using filter balls:

• One 1.5lb package of filter balls equals 50lbs of sand filtration capacity

• Pour the entire package into the tank

• Remove the shield (keep it for future filter ball replacement)

4. Sealing the System

• Place the O-ring into the tank top groove

• Install the 6-way valve, ensuring outlets face the pump

• Tighten the tank clamp with a screwdriver for secure connection

5. Connecting Pipes

• Apply Teflon tape to all threaded connections to prevent leaks

• Install 1.5-inch filter hose conversion adapters

• Connect the sand filter interconnecting hose (between pump and 6-way valve)

• Install the pressure gauge and viewing window

Installation to Pool System

1. Removing Old Pump

• Turn off power and drain water from old pump

• Disconnect hoses from old pump

• Remove old pump from bottom (may require assistance)

2. Installing Conversion Kit

• Install conversion kit at old pump location

• Seal unused openings with rubber plugs

• Ensure all connections are properly sealed

3. Connecting New System

• Connect new hoses from pool outlet to new pump inlet

• Connect pump outlet to pool return inlet

• Secure all connections with hose clamps

Initial Startup

1. Remove all temporary sealing plugs

2. Allow system to fill with water naturally, checking for leaks

3. Ensure 6-way valve is in "Filter" position

4. Connect to power

5. Press power button to start pump

CRITICAL SAFETY NOTE: Never operate the pump with valves closed as this will burn out the motor!

Operation and Maintenance

The AQUASTRONG sand filter pump offers simple operation:

• Single-button control

• Programmable 2-24 hour timer (in 2-hour increments)

• Pressure gauge for real-time system monitoring

With its powerful 2500 GPH flow rate, this pump significantly improves pool water circulation.

User Experience

After several days of use, the AQUASTRONG sand filter pump demonstrates excellent performance:

• Noticeably stronger water flow for better circulation

• Filter ball system is lightweight and easy to maintain

• Timer function provides energy-saving convenience

• Quiet operation with minimal vibration

Conclusion

The AQUASTRONG sand filter pump is a high-performance, easy-to-install solution for pool filtration. Whether replacing an old pump or upgrading your system, it delivers reliable filtration and powerful water flow. By following this guide, you can quickly complete installation and enjoy cleaner pool water.

Helpful Tip: If the water flow seems too strong, consider adding a pipe adapter to adjust the return jet direction.
